Great Clips Hair Salon TI Case Study

Guildford Village, Surrey, BC
  1. 1
    Feasibility & Demising Wall Review
  2. 2
    Accessibility & Barrier-Free W.C.
  3. 3
    Life Safety & 2-HR Fire Separation
  4. 4
    Permit Clearance (City of Surrey)
Project Type
Commercial TI
Location
Guildford Village,
Surrey, BC
Scope
Commercial TI Permit & Demising Wall
Facility
Great Clips (Guildford Village)
Client
Keith Chalmers
Jurisdiction
City of Surrey Building Division
Zoning & Area
C-8 Commercial • 957 SF Unit
Compliance
BC Building Code 2018 (Part 3 / Part 9)
Outcome
Successfully permitted & built
← Back to Commercial Projects

Expanding a prominent franchise into a newly subdivided retail unit requires precision code navigation. Canadian Blueprint partnered with franchise operator Keith Chalmers to deliver the complete permit drawings, life-safety compliance, and accessibility design for the 957 SF Great Clips salon at Guildford Village in Surrey, BC.

The Challenge

The project site in Guildford Village was created by demising an existing larger commercial retail shell into two separate lease spaces. Original municipal records lacked clear documentation for the newly constructed demising partition. The City of Surrey Building Division mandated rigorous proof of a continuous 2-hour fire-resistance rated assembly, along with strict compliance for universal barrier-free washroom clearances and egress travel distances in a high-turnover service occupancy.

Technical Scope of Work

Our team executed the complete commercial tenant improvement drawing package resolving all municipal requirements:

  • 2-Hour Fire-Separation Demising Wall: Specified and detailed ULC Design W453 (2 layers of 5/8" Type X gypsum wallboard on steel studs) ensuring continuous vertical and horizontal fire and smoke isolation between adjacent tenants.
  • Barrier-Free Universal Washroom: Engineered layout per BCBC 3.8.3.6, validating required turning radius circles, grab bar structural blocking, sink clearances, and self-closing door swing geometry.
  • Reflected Ceiling & MEP Coordination: Mapped integrated 10'-0" T-Bar ceiling grid, flat-panel lay-in LED lighting, track task lighting for styling stations, emergency egress fixtures, and supply/exhaust air diffuser locations.
  • Plan Checker Resolution: Addressed municipal deficiency items directly with City of Surrey plan checkers, confirming Architect exemption parameters for this tenant improvement scope.

The Outcome

Full City of Surrey Tenant Improvement Permit Clearance

By front-loading the ULC fire-separation details and coordinating all life-safety and accessibility requirements on Revit sheet sets, we eliminated municipal delays for the franchise operator. The salon opened smoothly at Guildford Village, providing high-volume haircare services to the Surrey community in a fully compliant, barrier-free environment.

Keith Chalmers
Keith Chalmers
Franchise Owner, Great Clips Surrey
"Edward was very helpful and knowledgeable. He cares, would definitely use them again!"
Edward Vega
Edward Vega
Certified Technician (CTech), ASTTBC, Canadian Blueprint Inc.
Owner Response
"Thank you Keith! It was great working with you on the Great Clips salon tenant improvement in Surrey and delivering your complete permit clearance."
